Cam lock type walk in freezer panels

Product Introduction:

Cam-Lock Type Walk-In Freezer Panels are PU insulated sandwich panels designed for walk-in freezer rooms, frozen food storage, cold chain facilities, and other low-temperature applications requiring reliable thermal insulation and secure panel connections.

The panels combine a high-density polyurethane (PU) foam core, durable metal skins, and an integrated heavy-duty cam-lock system. During installation, the cam-lock mechanism pulls adjoining panels tightly together, creating a strong and stable connection for the freezer enclosure.

These walk-in freezer panels are suitable for food storage, commercial refrigeration, food processing, distribution centers, cold chain logistics, and industrial freezer applications.

(0) Reviews

PRODUCT DESCRIPTION

Key Features of Cam-Lock Walk In Freezer Panels

· High-Performance PU Insulation – High-density polyurethane foam provides excellent thermal insulation for low-temperature freezer applications.

· Heavy-Duty Cam-Lock System – Integrated cam and pin assemblies securely pull adjoining panels together for a strong and stable connection.

· Fast & Convenient Installation – Prefabricated panels can be assembled efficiently, helping reduce installation time and labor costs.

· Excellent Thermal Performance – Low thermal conductivity helps minimize heat transfer and maintain stable freezer temperatures.

· Multiple Panel Thicknesses – Available in 50, 75, 100, 120, 150, 175, 200 and 250 mm options for different temperature requirements.

· Durable Metal Surface – Color-coated steel, stainless steel, aluminum, and galvanized steel surface options are available.

· Flexible & Modular Design – Suitable for customized room dimensions, layouts, door openings, and different freezer configurations.

· Secure Panel Connection – Mechanical locking provides consistent panel joining when properly aligned and sealed.

· Easy Maintenance & Potential Reuse – Where the system is designed for reuse, panels can be disassembled, relocated, and reassembled.

Range of Sandwich Panel Applications

Cam-Lock Type Walk-In Freezer Panels can be used for different temperature-controlled environments. The appropriate panel thickness should be selected according to the required storage temperature, ambient conditions, room dimensions, door opening frequency, product load, and refrigeration system design.

Cold Storage Category	Temperature Range	Typical Applications
Fresh-Keeping Cold Room	+5°C to -5°C	Storage of fruits, vegetables, flowers, dairy products, beverages, chocolate, butter, fresh eggs, fresh meat, and other fresh products.
Refrigerated Storage Room	-10°C to -20°C	Storage of frozen fish, frozen meat, poultry, eggs, and other frozen food products.
Freezing Storage Room	-20°C to -35°C	Low-temperature storage of fish and meat, rice and flour products, ice cream, blood products, chemicals, and other temperature-sensitive products.

Choosing the Right Panel

The required panel thickness should be selected based on:

· Required storage temperature

· Ambient temperature

· Cold room dimensions

· Door opening frequency

· Product temperature and load

· Required holding time

· Refrigeration system capacity

· Local installation conditions

For lower-temperature applications, thicker insulation is generally recommended to reduce heat transfer and help maintain stable internal temperatures.

Customized Walk-In Freezer Solutions

We manufacture Cam-Lock Type Walk-In Freezer Panels according to individual project requirements.

Customization can include:

· Panel thickness

· Panel dimensions

· Steel skin thickness

· Surface material

· Cold room configuration

· Floor and ceiling panels

· Door openings

· Special panel sections

· Installation requirements

Our walk-in freezer panels can be configured to meet different room sizes, temperature requirements, and installation conditions, providing a flexible solution for commercial and industrial cold storage projects.
