Ceiling Mounted Industrial Blast Freezer Evaporator
Product Introduction:
The Ceiling Mounted Industrial Blast Freezer Evaporator is designed for blast chilling and blast freezing applications, providing high airflow, efficient heat transfer, and reliable low-temperature performance.
Featuring a high-pressure fan system, optimized coil design, and durable casing construction, it ensures fast and uniform freezing for seafood, meat, poultry, food processing, and industrial cold storage applications.
The ceiling-mounted design saves floor space and improves air circulation, while different cooling capacities, fan configurations, coil designs, and defrost methods can be customized according to project requirements.
PRODUCT DESCRIPTION
Key Features
High Airflow Performance
· High-pressure axial fan motors provide powerful air circulation
· Optimized blade design ensures efficient airflow distribution
· Suitable for rapid chilling and freezing applications
Space-Saving Ceiling Mounted Design
· Ceiling installation reduces floor space requirements
· Optimized airflow distribution improves freezing performance
· Suitable for various industrial blast freezer layouts
Durable Industrial Construction
· Casing options:
o Pre-painted galvanized steel
o Stainless steel
· Excellent resistance to corrosion and impact
· Designed for continuous operation in demanding environments
Wide Temperature Range
· Operating temperature: -40℃ ~ +60℃
· Suitable for blast freezing and low-temperature cold storage applications
TECHNICAL DATASHEETS
Technical Specifications
Refrigerant: R404A | Fin Spacing: 12 mm | Condition: T₀ = -38°C, ΔT = 5K
Model | Cooling Capacity (kW) | Surface Area (m²) | Air Flow (m³/h) | Fan Qty. |
ATEN631D054E | 5.82 | 54 | 12,800 | 1 |
ATEN631D072E | 7.66 | 72 | 12,600 | 1 |
ATEN631D090E | 8.94 | 90 | 12,400 | 1 |
ATEN632D109E | 11.81 | 109 | 25,600 | 2 |
ATEN632D145E | 15.59 | 145 | 25,200 | 2 |
ATEN632D182E | 18.26 | 182 | 24,800 | 2 |
ATEN633D164E | 18.51 | 164 | 38,400 | 3 |
